When you are working with your golf cart and need an E-Z-GO TXT and T48 OEM Service Manual, you should stop right there and order one. No amount of internet research combined with guesswork will fill the gap between all of that and an official manual. There is just no substitute for all of the info and helpful procedures you are bound to find. Servicing your golf cart will no longer be a chore but an easy task on the list.
The service manual is for 2010 and up 48-volt E-Z-GO TXT and T48 models. It is what's considered an original equipment manufacturer or OEM text. This is not just some aftermarket troubleshooter. However, it will allow moderately proficient owners to service their golf carts with very little outside help. It comes with diagrams and instructions with all of the parts labeled with the OEM part numbers, so you can quickly call Buggies Unlimited and get those ordered. These books come directly from the factory and are hot off the presses, so please allow 3-4 weeks for delivery.
batteries are wired in series. The first battery in series positive terminal wires directly to the solenoid. The negative of that same battery wires to the positive of the second battery. The Negative of the 2nd battery goes to the positive of the 3rd. So on and so forth until you get to the last battery in series, that negative connects to the b- on the controller.
